FiiO KA11 Lightning | Portable headphone DAC and amplifier

70708
CHF49.00 Tax included
FiiO KA11 dongle with a CS43131 converter and a fixed Lightning cable, for Apple devices. 3.5 mm headphone output, 245 mW into 16 ohms, 384 kHz/32-bit and DSD256.
Color : Silver
Quantity
Add to wishlist
Supplier lead time, usually between 4 and 7 days

Guarantee safe & secure checkout

The black KA11 Lightning and its Lightning plug, seen at an angle

Straight into an iPhone

The Lightning cable is captive, 65.5 mm long, and links the dongle to an iPhone or an iPad with no adapter. The KA11 measures 44.5 x 9.7 x 10.5 mm and weighs 8.5 grams, in an aluminium-magnesium alloy shell. There is no battery and no switch: it draws its power from whatever it is plugged into.

The KA11 Lightning in its silver finish, seen at an angle

A dedicated CS43131

The converter is a Cirrus Logic CS43131, backed by an SGM8262 operational amplifier. The pair accepts up to 384 kHz at 32-bit as well as DSD256, and the KA11 is Hi-Res Audio certified. The circuit board is immersion gold-plated and the conductors are palladium-plated oxygen-free copper.

The silver KA11 Lightning stood upright, turquoise cable looped

245 mW of output

The 3.5 mm socket takes single-ended earphones and headphones. Into 16 ohms it delivers 245 mW per channel; 200 mW into 32 ohms and 22 mW into 300 ohms. The stated signal-to-noise ratio reaches 125 dB into 32 ohms, for a noise floor below 1.7 microvolts, an output impedance under 0.7 ohm and distortion under 0.0006%.

70708

Data sheet

Product Type
Portable USB DAC and headphone amplifier with a captive Lightning cable
Integrated DAC
Cirrus Logic CS43131 converter and SGM8262 operational amplifier, immersion-gold circuit board, palladium-plated oxygen-free copper conductors
Headphone output
3.5 mm single-ended headphone output
Output power
245 mW + 245 mW into 16 ohms, 200 mW + 200 mW into 32 ohms, 22 mW + 22 mW into 300 ohms; 125 dB signal-to-noise, noise floor under 1.7 µV, output impedance under 0.7 ohm
Connectivity
Captive 65.5 mm Lightning cable for iPhone and iPad, no adapter needed, aluminium-magnesium shell of 44.5 x 9.7 x 10.5 mm at 8.5 g
Hi-Res Audio
Up to 384 kHz at 32-bit and DSD256, distortion under 0.0006 % into 32 ohms, Hi-Res Audio certified
Series
KA
Width
4.5 cm
Depth
1.0 cm
Height
1.1 cm
Unit weight
0.0085 kg

Specific References

EAN13
6953175710677
