FREQUENCY RANGE - 20-22.000 Hz
Frequency Response - 20-20.000 Hz + 3 / - 1 dB
Tracking Ability at 315Hz at Recommended Tracking Force *) - 70 μm
Compliance, Dynamic, Lateral - 20 μm / mn
Stylus Type - Elliptical
Stylus Tip Radius - R / R 8/18 μm
*) Typical Value
Equivalent Stylus Tip Mass - 0.5 mg
Tracking Street - 1.6-2.0 g (16-20 mn)
Tracking Force, Recommended - 1.8 g (18 mn)
Angle Tracking - 20 °
Stylus Color - Translucent
Recommended for Following Cartridge - 2M Silver, Interchangeable With 2M Red and 2M Blue
Physically 2M Styli Will Fit On Alternative 2m Cartridge Bodies, Purpose 2M Series Cartridge 'Engines, Coils and Magnets Configurations Are Not Quite Identica: Red and Blue ARE Idential, So Are The Bronze and Black and So are The True Mono Variants 2m Mono and 2m 78.
2M Silver Phono Cartridge is an OEM (original Equipment Manufacturer) Model That Takes Most of the Characteristics of the 2M Red. 2m Silver's Special Feature Is Silver Copper Coils, The Same Coil Wire Material As In The 2M Bronze and Black Models, with a Reduced Number of Windings.
2M Series Styli AER Interchangeable Within The Below Combinations:
- 2M Red, 2m Blue and 2M Silver
- 2m bronze and 2m black
- 2m mono and 2m 78
Special for 2M Red, 2m Blue and 2M Silver Phono Cartridge:
- 2m Silver Will Be an Upgrade Compared to 2m Red Due to a special suspension and silver flat copper wire material.
- 2M Blue Is an Upgrade Compared to Both 2M Red and 2M Silver Thanks to Nude Elliptical Diamond Which Retrieves Information from The Groove with a Higher Accuracy.
