FREQUENCY RANGE: 20-24.000 Hz
FREQUENCY Response: 20-20.000 Hz + 3 / - 1 dB
Tracking ability at 315Hz at Recommended Tracking Force *): 70 μm
Compliance, Dynamic, Lateral: 25 μm / mn
Stylus Type: Elliptical
Stylus Tip Radius: R / R 8/18 μm
*) Typical Value
Tracking force range: 1.25-1.75 G (12.5-17.5 min)
Tracking Force, Recommended: 1.5 g (15 mn)
Angle tracking: 20 °
Stylus Color: Black
Recommended for Following Cartridge: Super OM 10, OM 10, OMP-MOUNT 10, Ombulk 10, OMT 10, LM 10, Concorde 10, Concorde EC 10, Concorde STD, TM 10h, LMB 12, SMB 12, LMA 12
FREQUENCY RANGE: 20-24.000 Hz
FREQUENCY Response: 20-20.000 Hz + 3 / - 1 dB
Tracking ability at 315Hz at Recommended Tracking Force *): 70 μm
Compliance, Dynamic, Lateral: 25 μm / mn
Stylus Type: Elliptical
Stylus Tip Radius: R / R 8/18 μm
*) Typical Value
Tracking force range: 1.25-1.75 G (12.5-17.5 min)
Tracking Force, Recommended: 1.5 g (15 mn)
Angle tracking: 20 °
Stylus Color: Black
Recommended for Following Cartridge: Super OM 10, OM 10, OMP-MOUNT 10, Ombulk 10, OMT 10, LM 10, Concorde 10, Concorde EC 10, Concorde STD, TM 10h, LMB 12, SMB 12, LMA 12
