The 2m Line Has Become has de facto reference for Moving-Magnet Cartridges ...
The 2m Black Is "Open, Fast, Detailed, Vivid, Full of Vitality and Sonically Spectacular.
Guarantee safe & secure checkout
Output Voltage at 1000 Hz, 5cm / sec. - 5 MV
Channel Balance at 1 kHz - 1 dB
Channel separation at 1 kHz - 26 dB
Channel separation at 15 kHz - 15 dB
Frequency Range AT - 3DB - 20-31.000 Hz
Frequency Response - 20-20.000 + 2 / - 0 dB
Tracking Ability at 315Hz at Recommended Tracking Force - 80 μm
Compliance, Dynamic, Lateral - 22 μm / mn
Stylus Type - Nude Shibata
Stylus Tip Radius - R / R 6/50 μm
Tracking Force Range - 1,4-1,7g (14-17 mn)
Tracking Force, Recommended - 1.5 g (15 mn)
Angle Tracking - 20 °
Internal Impedance, DC Resistance - 1.2 KOHM
Internal Inductance - 630 MH
Recommended Load Resistance - 47 KOHM
Recommended Load Capacitance - 150-300 PF
Cartridge Color, Body / Stylus - Black / Black
Cartridge Weight - 7.2 g
2M PNP MKII Cartridge with Integrated Headshell Weight - 20 g
2M PNP MKII Cartridge with Integrated Headshell Length - 52 mm
Replacement Stylus Unit - 2m Black (Interchangeable With 2M Bronze)
2m Black Verso Accessories Included The Package:
1. Remove The Stylus with the Stylus Protection Guard from the Cartridge Body to Avoid Any Damage to the Diamond.
2. Using Torx 8 Key, Unscrew The Black Screw from the verso Top Flat.
3. Remove The Top Flat from The Cartridge Body by Pullring The Screws Off.
4. Remove The Two Countrsunk Screws from The Top Flat.
5. INSERT THE TWO M2.0 mm Screws in the Top Flat.
6. Mount The Top Flat on the Cartridge Body. Hold The Top Flat With Screw-Threads Hanging Down and Turn The Cartridge Body 180 Degrees. Mount from Above.
7. Mount The Black Screw in The Top Plate and Tightten With Facility.
8. Mount The Cartridge on The TonaRM Using The Enclosed Tool.
9. Mount The Stylus with the Stylus Protection Guard on the Cartridge Body.
The 2M Black Is Graced With a Shibata Diamond Stylus - The Same Diamond AS on the Accladij mc Jubilee. ITS Slim, Highly Polished Profile Allows An Exceedingly Wide Contact Area To The Groove Walls and Ensoirs Notebly Detailed Playing Through The Spectrum, Including Even The Most High Frequency Groove Information.
The Cartridge Body Used for the 2m Black Is Manufactured from A Newly-Developed Lexan DMX Piano Black, A Revolutionary Material While Ensoires High Rigidity While Eliminating Unwanted Resonances.
The 2m Black USES has special upgraded engine, featuring split pole pines with a silver flat copper wire.
We have Optimized The Design for Ease of Mounting The Cartridge, and The Weight and Size to Fit The Most Common Turntable on the Market Today. The 2m Series Provids Excellent Compatibility When Used in An Assortment of Playback Systems and with a Wide Variety of Phono Preamps.
The 2M Series Is Developed in Conjunction With The Danish Industrial Designer Møller Jensen Design - The Same Designer Who Designed The Award Winning Mc jubilee and Kontrapunkt Series. Inspired by the features of a Diamond, Whose Outline Gracefully Trace The Grooves on A Record's Surface, The 2M's Handsome Elegance Establishes A Great Combination of Form and Functionality.
The Name 2M Was Selected from Among Several Ideas. We Wanted has Modern Name That Willd Be Easy To Pronounce and Remember, and Therefore An Alphanumerical Name Was Chosen. 2M Means MM, Which is the abbreviation for Moving Magnet.
Of Race The 2m Isn't Just Another Pretty Face. IT HAS BEEN ENGINEERED TO THE HIGHEST STANDARDS AND IS CONGRUENT WITH OrtofonUnrelenting commitment to providing The Most Precise and Accurate Reproduction possible without color.
The 2M Series of Cartridge Features Ortofon'S TRADEMARK SPLIT POLE PINS, AN OVER INVENTION THAT ENABLE MOVING MAGNET CARTRIDGES TO HAVE A FLAT FREQUENCY Response, as with a Moving Coil Cartridge. Split Pole Pins Were Injected by Ortofon, and Were Originally presented in the 500 Series and super OM Series.
We have Optimized The Design for Ease of Mounting The Cartridge, and The Weight and Size to Fit The Most Common Turntable on the Market Today. The 2m Series Provids Excellent Compatibility When Used in An Assortment of Playback Systems and with a Wide Variety of Phono Preamps.
