The AMU108 houses an 8-inch woofer with the same 2-inch compression driver as the 105. Power handling rises to 250 W AES and maximum output to 123 dB — 4 dB more for a cabinet twice as long.
Dispersion narrows to 90° horizontal and 60° vertical. This tighter pattern throws farther than the 105: it aims at a grandstand or field length rather than a compact zone.
Cabinet measures 49.8 cm wide, 23.5 cm tall, and 31.6 cm deep, weighing 10.6 kg. The U-bracket ships with the unit; inserts accept suspension rails, eyebolts, and pole adapters from the range.
Like the rest of the line, the cabinet is weather-resistant and meets EN 54-24. The 10, 20, 40, and 80 W taps cover the 100 V line; bypass mode converts the speaker to 8 Ω for low impedance.
