Naim New Classic Nap 250

Reference 69011

CHF6,999.00 Tax included

24‑hour delivery

The Naim NEW Classic NAP 250 is a stereo power amplifier of the New Classic 200 series. It delivers 100 watts per channel under 8 Ω via two XLR symmetrical inputs.

Description
Product Details

Naim New Classic Nap 250 Power Amplifier Vu Face Enfused

Power of 100 watts

The NAP 250 delivers 100 watts per channel under 8 Ω, measured at 0.1% THD + N. The exit stage works in class A / B; Two-thirds of nominal power and 1 kHz, distortion falls to 0.013%. The damping factor reaches 36 under 8 Ω and crosstalk between channels is 60 dB.

DR power regulation

The power supply is based on the DR regulation developed by Naim, which holds the tension served on the exit stages. The NA009 power transistors are resumed of the statement. A Foucault Current Separator completes the device.

Rear panel with the two symmetrical XLR inputs

XLR symmetrical inputs

Two symmetrical inputs on XLR have a 47 kΩ impedance; An asymmetrical link remains possible at 34 kΩ via an adapter cable. The clipping occurs at 1 input VRMS. Two XLR-XLR cords and an optical automation cable accompany the unit with the Power-Line Lite power cord.

Aluminum Front Face of the New Classic 200 Series

Aluminum chassis and dissipation

The cabinet is carved in thick aluminum plates, a selected choice at Naim To isolate the electronics of magnetic fields, temperature differences and vibrations. The heat sink prevents the rise in temperature with high levels of listening. The device measures 43.2 × 31.75 × 9.15 cm and weighs 16.8 kg. In operation, the consumption is 26 W, and descends under 0.5 W in standby.

Reference 69011

Data sheet
