Naim New Classic NAC 332 | Stereo preamplifier

Name: Naim New Classic NAC 332 | Stereo preamplifier
Brand: Naim
SKU: 70441
Price: 8999.00 CHF
Availability: InStock

Reference 70441

CHF8,999.00 Tax included

24‑hour delivery

The Naim New Classic NAC 332 is a preamplifier with eight assignable inputs on XLR, DIN and RCA. Its switched-resistor volume control, using reed relays, is derived from the Statement S1 preamplifier.

Description
Product Details

Rear panel and connections of the Naim New Classic NAC 332 preamplifier

Switched-resistor volume control

The volume control borrows the architecture of the Statement S1 preamplifier: reed relays switch a network of through-hole resistors instead of a potentiometer. This approach allows the sensitivity of each input to be adjusted and a maximum listening level to be set. The volume knob runs on a ball-race bearing, and the logo brightness is adjustable.

Eight assignable inputs

The eight input sockets comprise two XLR pairs loaded at 100 kΩ, one 8-pin DIN, two 5-pin DIN and three RCA pairs at 47 kΩ, rated for 2.2 V typical and 9.5 Vrms maximum. Each front-panel button can be assigned to the input of your choice. The 8-pin DIN socket supplies ±18 V for an external phono stage such as the NVC TT. Outputs are provided twice, on balanced XLR and on RCA, at 10 Vrms.

Chassis seen from three quarters, with front panel and volume knob

Headphone output and controls

The 6.35 mm front-panel jack is driven by a 1.5 W class A/AB headphone amplifier into 16 Ω. Eight buttons cover standby, mute and input selection, alongside the volume knob. The bi-directional Zigbee remote mirrors the Focal & Naim app, while a wireless link connects the unit to the NSS 333 streamer. An optical control also synchronises a New Classic amplifier such as the NAP 350.

Aluminium front panel and its volume knob

Measurements and power supply

On the line input, distortion is quoted at 0.003% at 1 kHz and 0.018% at 20 kHz, for a 2.2 V input and volume at 0 dB. Bandwidth covers 3 Hz to 40 kHz at -3 dB, crosstalk reaches 90 dB at 1 kHz and maximum gain is 15.5 dB. The unit measures 43.2 × 31.75 × 9.15 cm, weighs 11 kg and draws 20 W in everyday use. The NPX 300 external power supply can be added later.

Reference 70441

Data sheet

Product Type: Preamplifier
Features: Bi-directional Zigbee RF remote control
Eight buttons (standby, mute, inputs) and volume control
Focal & Naim app
Power supply upgrade: NPX 300
Zigbee link with the NSS 333
USB ports: Micro USB (update only)
Brand: Naim
Headphone output: 6.35 mm jack (1.5 W into 16 Ω)
Audio outputs: Balanced XLR + RCA
Integrated phono: No
Analog inputs: 1x 8-pin DIN, 2x 5-pin DIN, 3x RCA pairs (47 kΩ), 2x balanced XLR pairs (100 kΩ), 9.5 Vrms max
Phono inputs: 8-pin DIN with ±18 V for external phono stage (NVC TT)
Color: Black
Series: New Classic 300
Connections: 3.5 mm optical system-control output (NAP 250/350)
Signal-to-noise ratio: Line: 104 dB (2.2 V, A-weighted)
Power consumption: 20 W
Less than 0.5 W in standby
Less than 2 W (network standby)
Frequency response: Line: 3 Hz to 40 kHz (-3 dB)
Séparation des canaux: Line: 90 dB at 1 kHz, 70 dB at 20 kHz
Distortion (THD): Line: 0.003% at 1 kHz, 0.018% at 20 kHz (2.2 V, volume at 0 dB)
Width: 43.2 cm
Depth: 31.75 cm
Height: 9.15 cm
Unit weight: 11 kg
