Velodyne Acoustics VI-Q 15 | Active Subwoofer 15 Inch

Reference 72500

CHF2,499.00 Tax included

Supplier stock – typically 4 to 7 days

The Velodyne Acoustics VI-Q 15 is a 15-inch active subwoofer. Its Class D amplifier delivers 650 W RMS and its response reaches down to 23 Hz at ± 3 dB.

Color : Black

White
Black

Quantity

Add to wishlist

Supplier stock – typically 4 to 7 days

Description
Product Details

Black subwoofer in front of a wooden cabinet

15 Inch Carbon Cone

The 15 inch front-firing driver uses a carbon fibre cone with a convex profile, mounted on a high-excursion triple-vented basket. Its four-layer 3 inch / 76 mm voice coil limits partial vibration and therefore distortion. The baffle is cut from a 21-ply plywood board 50 millimetres thick.

Black subwoofer in a living room beside a record shelf

Class D Amplification

The Class D amplifier supplies 650 W RMS and 1200 W dynamic. Its switching power supply is built around two 25 A, 650 V MOSFET transistors. Response runs from 23 - 180 Hz at ± 3 dB and from 18 - 220 Hz at ± 10 dB.

Black subwoofer with its grille fitted, in front of books

iWoofer App

The iWoofer app gives control over room correction, a 25-band parametric equaliser and a set of presets. Adjustments are made from the listening position, without going back to the rear panel. The low-pass filter covers 50 to 180 Hz at 12 dB per octave and phase switches between 0 and 180 degrees.

Black subwoofer in front of a bookcase, cone exposed

Connections and Cabinet

The rear panel gathers gold-plated RCA stereo and LFE, nickel-plated XLR and a high-level input, with matching outputs. The cabinet is 22 millimetre HDF, offered in matte black or matte white. It measures 48 x 48 x 56 cm and weighs 32 kg.

Reference 72500

Data sheet
