Chassis: 2u
Optional mounting ears
Food: 240V AC / 50-60 Hz. OPTION: 130V AC
Consomation: 90 W max.
Weight: ~9,4kg
Environmental conditions:
- Operation: 0 ° C - 40 ° C (32 ° F - 104 ° F)
- Moisture: 20% - 80% relative humidity (without condensation)
Introduction
Acoustic loyalty
The critical element of any sound reproduction system is the listening environment. Typically, the piece introduces a significant amount of disturbances, which led us to question the fidelity of a listening system, as high-end, in an uncontrolled acoustics.
The Trinnov St2-HiFi solves This acoustic equation and restore your system all its nobility. Listening wins in equilibrium and precision. Its intrinsic qualities are revealed and your favorite works can finally be returned with the details they deserve.
In summary
The ST2-HiFi is the most sophisticated pregnant / piece optimizer. It offers pregnant optimization technologies / patented part by Trinnov In a product dedicated to audiophiles.
The ST2-HiFi offers the following advantages:
- Easy installation in 4 steps,
- Powerful algorithms: multi-point measurements, time-frequency analysis, full graphic representations and more ...
- Flexibility of setting up your personal criteria for tonal equilibrium,
- High performance audio cards designed and manufactured by Trinnov,
- Multiple remote control options.
- Stylish, sober and modern design.
Features
Ease of installation
- Insert the system between your player / preamp and power amps and connect the 3D microphone
- Follow the calibration wizard step by step
- Listen to one of the 5 optimizations generated automatically
- Change the optimization settings and establish a target curve
- Record up to 6 customizable profiles and 29 users' presets.
Powerful algorithms
- Multi-point measures of all speakers
- Time-Frequency Analysis: Speakers and the room are analyzed separately
- Complete acoustic graphic representations
- Acoustic optimization of the amplitude and the response in phase according to a target curve
- Intelligent active filtering: automatic alignment of gains and delays of each of the speakers
Flexibility of parameterization
- Optimization modes: amplitude + phase, single amplitude, low-ranging single, according to the left-right speakers
- Complete acoustic curves
- Optimization Settings: Max Boost, Max Attenuation, Quantity of Early Reflection, Energy of the Part
- Manual Fir, Graphic and Parametric EQS
Remote control
- Display screen + order
- Touch screen (optional)
- Network control from a PC, Mac, iPad, iPhone or Android devices through the VNC protocol
- Home automation control, Ethernet and RS232
Options
USB Wi-Fi Antenna
The ST2 HiFi has a port Ethernet (RJ45) Integrated This allows it to connect to your local network via an Ethernet cable. Integrated VNC technology is the best solution to control the HiFi ST2 across the network from a tablet, computer or smartphone. The optional Wi-Fi antenna adds the wireless connectivity. It allows the ST2 HiFi to connect to your Wi-Fi network, or act as a Wi-Fi access point (AP).
Software update
Software update can be purchased to take advantage of new features and the latest versions of the algorithms.
3D microphone
The measuring microphone is optional.
