Classe audio CA-5300 occasion revisée

Marque:

Appareil d'occasion garanti 2 ans

Lire la suiteShow less
Offre spéciale limitée
3 900,00 CHF TTC
Lancé à 13 500,00 CHF
Derniers articles en stock
Référence:
56370
Aimer0
Ajouter à la comparaison0
Ajouter à la liste de souhaits
Description

Our Delta series amplifiers embody all that Classé represents: innovation, technological achievement, consummate craftsmanship, and iconic design. But they are not just the latest in the distinguished line of Classé amplifiers to be launched since 1980. They are new, revolutionary and unique.

Performance first
The original Delta series amplifiers won more than critical acclaim. Elite audio professionals use them to master music and movies that the whole world has enjoyed. Our newest amplifiers are even better. Objectively, pure technical measurements prove they deliver our highest performance ever. Subjectively, they simply blow audiences away.

The Classé design team has created the ultimate environment to amplify an audio signal. The entire amplification process occurs on a single board, creating the most direct and transparent signal path conceivable. Our uniquely miniaturized driver stage is virtually noise free, so every nuance of the original signal reaches the output stage. Here, vast quantities of clean power are controlled with absolute precision. Suddenly, the world’s finest speakers sound even better.

Performance fast
There is a relationship between temperature and performance but it is widely misunderstood. Audiophiles say that optimal performance is obtained when an amplifier is “warmed up,” but what does this actually mean? When is it warm enough and when is it too warm?

The exposed heatsink fins found on conventional amplifiers are passive.They can’t help circuits reach their ideal temperature or keep them there throughout a listening session. They run at a temperature wholly defined by their environment and how loud they are playing. This can be far from ideal.

Heat management in Classé’s new Delta series amplifiers is provided by the ICTunnel™ (pronounced Icy Tunnel), a sensor- and microprocessor-controlled technology inspired by the heatsinks found in high-power laser and medical equipment. Mounted inside the unit, the ICTunnel™ actively regulates the amplifier temperature to ensure both optimum performance and reliability.

From room temperature, the amplifiers warm up fast. They reach their ideal temperature in less than fifteen minutes and remain there regardless of how hard they are driven. No conventional heatsink can do this.

In a Class by itself
Ground-breaking performance, prodigious power, sophisticated control and rock-steady reliability—Classé’s new Delta series is a giant leap in amplifier design. Thanks to exclusive ICTunnel™ and audio technologies, only Classé amplifiers can consistently deliver top performance and reliability in every installation.



All tests un-weighted and 500kHz measurement bandwidth (except SNR).

Frequency response



1 Hz – 100 kHz, -3dB

Output power



300W rms into 8Ω (24.8 dBW)
All channels driven*

Harmonic Distortion



<0.002% at 1 kHz balanced
<0.004% at 1 kHz single ended

Peak Output Voltage



167V peak to peak, 53V rms no load
156V peak to peak, 48V rms into 8Ω

Input Impedance



50kΩ balanced / single ended

Voltage gain



29dB balanced / single ended

Input level at clipping



2.1V rms balanced / single ended

Intermodulation
Distortion



>90dB below fundamental into

>90dB below fundamental into
8Ω balanced / single ended

Signal to Noise Ratio



-116dB at peak output into 8Ω
Measurement Bandwidth: 22 kHz

Output impedance



0.03Ω @ 1 kHz

Standby power
consumption



< 1W

Rated power
consumption



1300W @ 1/8th power into 8Ω

Width



17.5” (444mm)

Depth



22.52” (572mm) (excluding connectors)

Height



8.78” (223mm)

Gross weight



115 lb (52.3 kg)

Net weight



105 lb (47.7 kg)

Mains voltage



Specified on rear panel

* Specifications for output into 4 ohms are omitted because the AC Mains/power supply cannot support all channels driven simultaneously at this level, which would require over 5,000W and only occur under a special test condition. The amplifier easily drives lower impedance loads.

Lire la suiteShow less
Détails du produit
56370

Fiche technique

Type de produit
Amplificateur de puissance
Nombre de canaux
5
Vitesse de rotation
33 rpm
45 rpm
